Rexing M2 Smart Mirror Dash Camera User Manual

The Rexing M2 Smart Mirror Dash Camera is a dual-channel dash cam that attaches to your rearview mirror and offers a 12 IPS touchscreen for viewing the rear camera. Capture 2K1080p video from both cameras simultaneously, with the QHD 1440p front camera and the Full HD rear camera. The M2 features Advanced Driver Assisted Systems (ADAS) such as Blind Spot Detection, Lane Change Assist, Cross Traffic Alerts, and Parking Assistance.

Introduction

Welcome to the Rexing M2 Smart Mirror Dash Camera User Manual. This manual will guide you through the features, installation, operation, and maintenance of your new Rexing M2 dash camera. The Rexing M2 is designed to provide you with peace of mind while driving, offering reliable video recording and advanced safety features to enhance your driving experience.

The M2 is a sophisticated dash camera that combines a crystal-clear 12 IPS touchscreen with a dual-channel recording system, capturing high-quality video from both the front and rear cameras simultaneously. The front camera boasts a QHD 1440p resolution, while the rear camera records in Full HD 1080p, ensuring detailed footage of your surroundings.

Beyond its exceptional video capabilities, the Rexing M2 also incorporates Advanced Driver-Assisted Systems (ADAS) to promote safer driving. These features include Blind Spot Detection, Lane Change Assist, Cross Traffic Alerts, and Parking Assistance, providing helpful warnings and alerts to help you stay aware of potential hazards on the road.

This manual is your comprehensive resource for understanding and using your Rexing M2 dash camera effectively. It covers essential topics such as unboxing and contents, installation, memory card usage, video recording, playback, ADAS features, troubleshooting, and warranty information.

Features

The Rexing M2 Smart Mirror Dash Camera is packed with features designed to enhance your driving safety and provide you with comprehensive video recording capabilities. Here’s a closer look at the key features of the M2⁚

• Dual-Channel Recording⁚ Capture video from both the front and rear cameras simultaneously. The front camera records in QHD 1440p resolution, while the rear camera records in Full HD 1080p, ensuring detailed footage of your surroundings.
• 12 IPS Touchscreen⁚ Enjoy a crystal-clear view of your rear camera footage on the large 12-inch IPS touchscreen. The intuitive touch interface allows for easy navigation and control of the camera’s settings.
• Advanced Driver-Assisted Systems (ADAS)⁚ The M2 incorporates ADAS features to enhance your driving safety. These features include⁚
• Blind Spot Detection⁚ Provides visual and audio alerts when a vehicle is detected in your blind spot, helping you change lanes safely.
• Lane Change Assist⁚ Warns you if you drift out of your lane unintentionally, helping to prevent accidents.
• Cross Traffic Alerts⁚ Notifies you of approaching vehicles while reversing, enhancing your awareness of potential hazards.
• Parking Assistance⁚ Provides visual guidelines on the touchscreen to aid in parking maneuvers, making it easier to park in tight spaces.
• GPS Logger⁚ Track your location and speed with the built-in GPS logger. This information can be helpful for identifying your location in case of an accident or for analyzing your driving habits.
• Night Vision⁚ The M2 utilizes advanced night vision technology to capture clear video footage even in low-light conditions. This ensures that you have a clear record of events, even during nighttime driving.
• G-Sensor⁚ The built-in G-sensor automatically detects sudden impacts or collisions. When triggered, it locks the current video file to prevent it from being overwritten, preserving crucial evidence in case of an accident.
• Parking Monitor⁚ The M2’s parking monitor feature continues recording even when the vehicle is parked. If motion is detected, the camera automatically starts recording, providing an extra layer of security when your vehicle is unattended.

These advanced features make the Rexing M2 a comprehensive and reliable dash camera that can provide peace of mind while driving.

Unboxing and Contents

Upon opening the box of your new Rexing M2 Smart Mirror Dash Camera, you’ll find the following components, carefully packaged to ensure safe arrival⁚

1. Rexing M2 Smart Mirror Dash Camera⁚ The heart of the system, featuring a 12-inch IPS touchscreen, dual-channel recording capabilities, and advanced ADAS features.
2. Rexing Rear Camera⁚ A high-resolution camera designed to capture clear video footage of the area behind your vehicle, providing a wide-angle view of traffic and potential hazards.
3. GPS Logger⁚ A small device that connects to the M2 and records your location and speed, providing valuable information for accident reconstruction or driving analysis.
4. In-Car Power Cable (12ft)⁚ A long power cable designed to reach from the power source (usually your vehicle’s cigarette lighter) to the M2, ensuring a secure connection.
5. Rear Camera Cable⁚ A cable that connects the rear camera to the M2, allowing you to transmit video footage from the rear camera to the M2’s touchscreen.
6. Cable Management Tool⁚ A tool designed to help you organize and secure the cables for a neat and tidy installation within your vehicle.
7. User Manual⁚ A comprehensive guide that provides detailed instructions on setting up, using, and maintaining your Rexing M2 Smart Mirror Dash Camera. It covers everything from basic operation to advanced features and troubleshooting tips.
8. Warning Sticker⁚ A sticker designed to be placed on your vehicle to alert other drivers that you have a dash camera installed. This can help deter potential theft and discourage reckless driving.
9. 2 Sets of Rubber Mounting Straps⁚ These straps securely attach the M2 to your rearview mirror, ensuring a stable and reliable installation.

With these components in hand, you are ready to install and start enjoying the benefits of the Rexing M2 Smart Mirror Dash Camera.

Installation

Installing the Rexing M2 Smart Mirror Dash Camera is a straightforward process, designed to be user-friendly and minimize the need for complex wiring or modifications to your vehicle. Here’s a step-by-step guide⁚

1. Install the Front Camera⁚ Begin by plugging the power cable into your vehicle’s cigarette lighter. Then, carefully attach the M2 to your rearview mirror using the provided rubber mounting straps. Ensure that the M2 is securely fastened and positioned at a comfortable viewing angle. Connect the power cable to the M2, making sure the unit is turned off.
2. Insert the SD Card⁚ Before turning on the M2, insert the micro SD memory card into the designated slot. The M2 supports cards up to 256GB. It’s crucial to use a micro SD card with a Class 10 / UHS-I or higher speed rating for optimal performance. Formatting the SD card is recommended before using it for the first time.
3. Install the Rear Camera⁚ Once the front camera is mounted and the SD card is inserted, proceed to install the rear camera. The rear camera is designed to be discreetly mounted above your license plate, providing a clear view of the area behind your vehicle. Use the adhesive mount to secure the rear camera in place, ensuring it is facing the rear of your vehicle.
4. Connect the Rear Camera Cable⁚ Connect the rear camera cable to the corresponding port on the M2. The cable should be routed neatly along the roof of your vehicle, ensuring it does not obstruct any critical features or hinder your driving experience.
5. Power On and Format SD Card⁚ Turn the M2 on and format the SD card if you haven’t already done so. The M2 will automatically start recording video footage once it is powered on and the SD card is formatted. You can customize the recording settings, such as resolution, frame rate, and recording duration, through the M2’s menu settings.

With these steps completed, your Rexing M2 Smart Mirror Dash Camera is installed and ready to capture your driving experiences, providing you with peace of mind and valuable evidence in case of an incident.

Memory Card

The Rexing M2 Smart Mirror Dash Camera relies on a micro SD memory card to store your recorded video footage. Choosing the right memory card is essential for optimal performance and reliable recording capabilities. Here’s what you need to know about memory cards and the M2⁚

Memory Card Requirements⁚

• Type⁚ The M2 requires a micro SD memory card.
• Speed Rating⁚ It’s crucial to use a card with a Class 10 / UHS-I or higher speed rating to ensure smooth recording and prevent dropped frames. A higher speed rating allows the camera to write data to the card quickly, guaranteeing uninterrupted recording.
• Capacity⁚ The M2 supports cards up to 256GB in capacity. The amount of storage you need will depend on your individual recording preferences and how often you intend to review or delete footage.

Choosing the Right Memory Card⁚

When selecting a memory card for your M2, prioritize the speed rating and capacity based on your needs. Consider factors like how frequently you drive and how long you want to retain recordings. It’s advisable to choose a card specifically designed for dash cam use, as these cards are typically optimized for continuous recording and high-speed data transfer. Refer to the latest card recommendations from Rexing for guidance on compatible and recommended cards.

Formatting Your Memory Card⁚

It’s essential to format a new micro SD card before using it with the M2. Formatting ensures the card is properly initialized for use with the camera. You can format the card using the M2’s built-in formatting function, which can be accessed through the Setup Menu. Before formatting, always back up any important data stored on the card, as formatting will erase all data.

Video Recording

The Rexing M2 Smart Mirror Dash Camera is equipped to capture high-quality video footage while you’re on the road. Its dual-channel recording system allows you to record from both the front and rear cameras simultaneously, providing comprehensive coverage of your surroundings. Here’s a breakdown of the M2’s video recording capabilities⁚

Resolution and Frame Rate⁚

• Front Camera⁚ The M2’s front camera records in QHD (1440p) resolution at 30 frames per second, delivering clear and detailed footage. The wide-angle lens captures a broad field of view, ensuring that you capture all the important details on the road.
• Rear Camera⁚ The rear camera records in Full HD (1080p) resolution at 30 frames per second. It provides a clear view of the traffic behind your vehicle, especially helpful for backing up or navigating tight spaces.

Video Recording Modes⁚

The M2 offers various recording modes to suit your needs. You can choose between continuous recording, which records footage continuously until the memory card is full, and event recording, which triggers recording when the camera detects a sudden impact or movement. The event recording feature helps preserve crucial footage in case of an accident.

Loop Recording⁚

To ensure continuous recording, the M2 utilizes loop recording. When the memory card is full, the camera automatically overwrites the oldest files with new recordings. This feature helps you preserve the most recent footage without needing to manually manage the card. You can adjust the loop recording time interval to your preference.

Night Vision⁚

The M2 incorporates advanced night vision technology that enhances visibility in low-light conditions. It uses a sensitive image sensor and infrared LEDs to capture clear and detailed footage even in the dark, ensuring your surroundings are captured clearly, even at night.

Playback

Reviewing your recorded videos is straightforward with the Rexing M2 Smart Mirror Dash Camera. The M2 offers multiple ways to access and view your recordings, whether you want to check them on the device itself or on your computer or mobile device; Here’s a guide to the M2’s playback features⁚

On-Device Playback⁚

The M2’s 12 IPS touchscreen provides a clear and intuitive interface for playback. To view your recordings directly on the device, follow these steps⁚

1. Stop Recording⁚ Press the REC button to stop the current recording.
2. Switch to Playback Mode⁚ Press the MODE button twice to switch from Recording to Playback Mode.
3. Navigate Through Files⁚ Use the UP or DOWN button to scroll through the stored video files. You can select a specific file to view.
4. Playback Controls⁚ The touchscreen allows you to play, pause, rewind, and fast-forward through your recordings. You can also zoom in and out on the video to view details more clearly.

Playback on Computer or Mobile Device⁚

For convenient playback on your computer or mobile device, follow these steps⁚

1. Remove Memory Card⁚ Carefully remove the memory card from the M2 camera.
2. Insert into Card Reader⁚ Insert the memory card into a card reader connected to your computer or mobile device.
3. Access Files⁚ Your computer or mobile device will recognize the memory card, and you can access the recorded video files. You can then play them back using your preferred video player.

The M2 offers a user-friendly experience for reviewing your recordings, whether you prefer to view them directly on the device or on your computer or mobile device.

Advanced Driver-Assisted Systems (ADAS)

The Rexing M2 Smart Mirror Dash Camera is equipped with a suite of Advanced Driver-Assisted Systems (ADAS) designed to enhance your driving safety and awareness. These features utilize the camera’s sensors and processing power to monitor your surroundings and provide timely alerts for potential hazards. Here’s a breakdown of the key ADAS features offered by the M2⁚

Blind Spot Detection (BSD)⁚ This feature helps prevent collisions by detecting vehicles in your blind spots when changing lanes. The M2 will alert you with a visual and audible warning if a vehicle is detected in your blind spot.

Lane Change Assist (LCA)⁚ Designed to enhance lane discipline, LCA monitors lane markings and alerts you with visual and audible warnings if you drift out of your lane unintentionally. This can be particularly helpful during long drives or when fatigued.

Cross Traffic Alert (CTA)⁚ When reversing from a parking spot or driveway, CTA helps you avoid collisions with vehicles approaching from the sides. The system uses the rear camera to detect approaching vehicles and alerts you with visual and audible warnings.

Parking Assistance⁚ The M2’s Parking Assistance feature provides visual guidance when maneuvering in tight spaces. This can be especially helpful when parking in parallel or perpendicular spots, making the process smoother and less stressful.

These ADAS features work together to provide a comprehensive safety net, enhancing your awareness of your surroundings and potentially preventing accidents. Remember to calibrate the ADAS system properly according to the instructions in the user manual to ensure optimal performance.
